F2F Decoder IC

　

F2F Decoder IC
Very few external components required
　

BS720Q /QFN 16
Dual Track 4 x4 mm
　
BS720S /SOP16
Dual Track 9.90 x 3.90mm
BS730Q /QFN 24
Triple Track 4 x 4 mm

For more information, please contact adomo.tech@msa.hinet.net 　

 Main Features :
  • 0.5um CMOS ASIC IC for F2F magnetic stripe card reader.
  • Against the interference from Electronic Article Surveillance (EAS)
  • Very few external components, can be built inside Mag. Head .
  • Built-in operational amplification circuitry.
  • Low power: Current Max. 3.3mA, best for portable, hand-held devices.
  • Operational power DC 2.7V ~ 5.5V
　

Applications :

  • Magnetic Card Reader
  • CAT (Card Authorization Terminal)
  • POS Keyboard
  • Security Control

　

Magnetic Card Reader

　

TTL Interface – triple track TL Series
　

TL730A
TL730B

For more information, please contact adomo.tech@msa.hinet.net 　

 Main Features :
  • ISO standard
  • RoHS compliant
  • TTL Interface
  • FPCB or wire assembly can be customized
  • Several sizes of swiping slot
  • OEM production is welcome
　

　

TTL Interface – triple track MH Series

　

MH200-AK MH300-AK MH730A

For more information, please contact adomo.tech@msa.hinet.net 　

 Main Features :
  • ISO standard
  • RoHS compliant
  • TTL Interface
  • FPCB or wire assembly can be customized
  • Can be fixed on several sizes of swiping slot
  • OEM production is welcome
